Clinical Features
Digital Mobile X-ray designed in Sweden
with the radiographer and patient in mind
Powerful high frequency X-ray generator for super-sharp images
Adjustable height of drive
handle for better ergonomics
handle for better ergonomics
Storage for
additional detectors
additional detectors
Advanced X-tech Cell®
battery technology
battery technology
Large touchscreen user-Interface & image display with angle adjustment
Fully collapsible
motorised column
motorised column
Status indicator light
Covers and cables
designed for easy cleaning
designed for easy cleaning
The smallest and most
lightweight mobile available
lightweight mobile available
Sold exclusively in the UK and Ireland by Xograph Healthcare
Designed to be moved
with clear lines of sight
One of the smallest & lightest
mobile X-ray units available
- ○ Easy to manoeuvre throughout the hospital, even in small spaces
- ○ Fully collapsible column provides a clear, unobstructed view ahead
- ○ Enables operators to get from A to B quickly and with confidence
Wireless Canon DR detector
technology on board
27 x 35 cm
35 x 43 cm
43 x 42 cm
Canon detector system - accomplished & reliable
- ○ Three sizes, all wireless, shareable across modalities
- ○ Up to 60% dose reduction and no physical grid
- ○ Instant, high quality image review
The advantages of Canon DR Detectors
Trusted. Robust. Reliable
2.3
kg detector
125
Microns pixel pitch
60
% Dose reduction
7
IPX waterproof
The advantages of X-Tech cell batteries
All this on a single charge
10
Seconds start up
1200
Exposures energy
15
Kilometres range
9
Hours of use
Exposure status at a glance
A visual signal for staff & patients
even in the noisiest environment
- ○ For ward staff & carers: when the light goes green → step away
- ○ For patients: when the light goes green → keep very still / hold your breath
Blue: Operational
Green: Exposure
preparation
Yellow: Exposure underway
A revolution in battery performance
Most mobile X-ray units use yesterday’s lead acid batteries.
The M1 Mobile uses advanced lithium X-tech Cell® technology
- ○ Just 1.5 hours of charge gives 9 hours of operation
Lead Acid batteries
Multiple batteries requiring regular
replacement, as found in most other
mobile X-ray units
replacement, as found in most other
mobile X-ray units
8 hours to charge
5 hours of system operation
X-tech Cell®
An advanced lithium battery pack
only found on Xograph’s Mobile
X-ray unit
only found on Xograph’s Mobile
X-ray unit
1.5 hours to charge
9 hours of system operation
M1 Mobile
Size. Power. Endurance.
Smallest & lightest
- effortless manoeuvrability
Lifetime battery
- no replacements required
Hypercharge
- just 10 minutes gives 1 hour’s use
Lowest column
- clear view forward
RIS & PACS view
- one convenient interface
Powered by Canon DR
- proven over 20 years; robust & reliable
Hypercharge: no more ‘dead’ mobile X-ray units
Lead Acid batteries
Multiple batteries requiring regular replacement,
as found in most other mobile X-ray units
as found in most other mobile X-ray units
10mins of charge
= 5 mins of use
45
15
0
30
X-tech Cell®
An advanced lithium battery pack
only found on Xograph’s Mobile X-ray unit
only found on Xograph’s Mobile X-ray unit
10mins of charge
= 60 mins of use
45
15
0
30
- ○ Increases productivity of radiographers by ensuring the mobile is always available for use
- ○ Never again worry about a ‘flat' battery
- ○ No need for spare mobiles to ‘pick up the slack’
Create a revolution in your department
- More house of operation offers scope to reduce your mobile X-ray fleet without compromising productivity.
- Fewer mobile X-ray units means lower capex and lower maintenance costs.
Lead Acid batteries
Operation
5 hours
Charging
8 hours
Operation
5 hours
Charging
8 hours
Across a 12 hour working day
8 hours of charging
5 hours of operation
X-Tech Cell ® advanced new batteries
Operation
9 hours
1.5 hours
Operation
9 hours
1.5 hours
Operation
9 hours
Across a 12 hour working day
Just 1.5 hours of charging
9 hours of operation
Innovation
Intelligent design – with the radiographer in mind
17” adjustable hi-res
touchscreen display
For image preview, management and all exam. control
Integrated detector
battery charger
Simultaneously charge two batteries
Easy cleaning of
covers & cables
Designed with infection control in mind
Height and
reach adjustment
To reduce back strain and stress on operators
Integrated
DAP meter
Internal within the collimator - no external cables
Scatter
correction
High contrast, scatter-free imaging
without increasing patient dose
without increasing patient dose
Storage for
additional detector
Slots for two Canon detectors
Wireless
remote control
for exposure and LED collimator light
About Xograph
Dedicated to diagnostic medical imaging
At Xograph we’re committed to diagnostic medical imaging – this is what we’ve been doing for 50 years.
We are independent of any manufacturer – and so able to select the very best, most innovative products available.
- ○ Surgical c-arms
- ○ Mobile & Portable DR
- ○ Static DR systems
- ○ Mammography
- ○ DR dental
- ○ Extremity CT
Nationwide technical support.
Our customers are supported by over 40 experienced engineers and product specialists, covering all areas of the UK and Ireland.
- ○ Our group headquarters and test facilities are in Stonehouse, Gloucestershire, UK, with our Ireland office in Dublin.
- ○ We are ISO 13485 certified, have access to N3 and are present on all major NHS supply frameworks.
The sensational new M1 Mobile is supplied
in the UK & Ireland exclusively by Xograph
Contact us now to find out more
Book A Test Drive
